主要用途Main application
自動計量封包裝袋機是一種按照事先設計好的程序和方式,將粉狀的物料自動分裝成預定重量的設備。
Automatic weighing and packing machine is to pack the rubber powder automatization at a predetermined weight according to the pre-desighed procedures and methods.
設備特點Equipment features
操作簡單,自動化程度高,計量精度高Simple operation, high automation and measuring accuracy.
工作可靠, 穩定性好Running reliability and stability.
裝包量(儀表預置點)調整簡單方便Easy to adjust for measuring.
能進行提前量修正和自動故障診斷Advance modification and self-detecting.
能自動進行空秤檢測、清零以及自動計數。Automatic detection of empty scale, cleared and automatic counting.
主要技術參數Main technical spec
設備型號Equipment model | XK3190 |
包裝重量 Package weight（bag/h） | 20～40 |
最大包裝能力Max packaging capacity（Kg） | 50～100 |
計量精度Measurement accuracy | ±0.2%～0.6% |
電機功率Motor Power （Kw） | 1.5 |
計量準確度Accuracy of measuring | ±0.2%（10 包平均Bags average） |
使用氣壓Air pressure (MPa) | 0.5～0.6 |
外形尺寸Size (L×W×Hmm) | 1450×1200×3200 |
設備重量Equipment weight（Kg） | 350 |
